UniFi Switching & Routing
High-Performance Routing and Advanced Security & Network Switching


UniFi Security Gateway
High-Performance Routing and Advanced Security

The UniFi Security Gateway extends the reach of the UniFi Enterprise System to route, secure, and manage your network for optimal performance and reliability.

UniFi Security Gateway Products

UniFi Security Gateway

UniFi Security Gateway

  • (3) 10/100/1000 RJ45 Ports
  • (1) RJ45 Serial Console Port
  • Quiet, Fanless Operation
  • Wall-Mounting Capability
  • Layer 3 Forwarding Performance

UniFi Security Gateway Pro


UniFi Security Gateway Pro

  • (2) 10/100/1000 RJ45 Ports
  • (2) 10/100/1000 RJ45/SFP Combination Ports
  • (1) RJ45 Serial Console Port
  • Rack-Mounting Capability
  • Layer 3 Forwarding Performance

UniFi Switch
Advanced Network Switching

Managed by the UniFi Controller software, the UniFi Switch delivers powerful performance, intelligent switching, and PoE+ support for your enterprise networks.

UniFi Switch Products

UniFi Switch 6 XG

  • (4) 100/1000 Mbps and 2.5/5/10G RJ45 Ports
  • (2) 1/10G SFP+ Ethernet Ports
  • Ethernet In-Band (1) RJ45
  • Serial Port Out-of-Band
  • (1) USB Type C Port Out-of-Band
  • 54VDC, 3.88A Power Adapter
  • External AC/DC Adapter

UniFi Switch 8

  • (8) Gigabit RJ45 Ports
  • (1) PoE Passthrough Port
  • Non-Blocking Throughput: 8 Gbps
  • Switching Capacity: 16 Gbps
  • Forwarding Rate: 11.9 Mpps
  • Maximum Power Consumption: 12W
  • PoE or DC Input Option
  • Available in Single-Pack and 5-Pack
    (Power Supply Not Included with 5-Pack)

UniFi Switch 8-60W

  • (8) Gigabit RJ45 Ports
  • (4) Auto-Sensing IEEE 802.3af PoE Ports
  • Non-Blocking Throughput: 8 Gbps
  • Switching Capacity: 16 Gbps
  • Forwarding Rate: 11.9 Mpps
  • Maximum Power Consumption: 12W
  • Available in Single-Pack and 5-Pack

UniFi Switch 8 150W

  • (8) Gigabit RJ45 Ports
  • (2) SFP Ports
  • Non-Blocking Throughput: 10 Gbps
  • Switching Capacity: 20 Gbps
  • Forwarding Rate: 14.88 Mpps
  • Maximum Power Consumption: 150W
  • Supports POE+ IEEE 802.3at/af and 24V Passive PoE
  • Quiet, Fanless Operation
  • Rackmountable with Rack-Mount Brackets (Included)
  • Desktop-Mountable

UniFi Switch 16

  • (16) Gigabit RJ45 Ports
  • (2) SFP Ports
  • (1) Serial Console Port
  • Non-Blocking Throughput: 18 Gbps
  • Switching Capacity: 36 Gbps
  • Forwarding Rate: 26.78 Mpps
  • Maximum Power Consumption: 150W
  • Supports POE+ IEEE 802.3at/af and 24V Passive PoE
  • Rack-Mountable or Wall-Mountable with Rack-Mount Brackets

UniFi Switch 16 XG

  • (12) 1G/10G SFP+ Ports
  • (4) 1G/10G RJ45 Ports
  • (1) RJ45 Serial Console Port
  • Non-Blocking Throughput: 160 Gbps
  • Switching Capacity: 320 Gbps
  • Forwarding Rate: 238.10 Mpps
  • Rack Mountable with Mount Brackets (Included)
  • DC Input Option (Redundant or Stand-Alone)

UniFi Switch 24

UniFi Switch 24

  • (24) Gigabit RJ45 Ports
  • (2) SFP Ports
  • (1) Serial Console Port
  • Non-Blocking Throughput: 26 Gbps
  • Switching Capacity: 52 Gbps
  • Forwarding Rate: 38.69 Mpps
  • Maximum Power Consumption: 25W
  • Rack-Mountable

UniFi Switch 24 PoE

UniFi Switch 24 PoE

  • (24) Gigabit RJ45 ports
  • (2) SFP ports
  • (1) Serial console port (reserved for future use)
  • Non-blocking throughput: 26 Gbps
  • Switching capacity: 52 Gbps
  • Forwarding rate: 38.69 Mpps
  • Maximum power consumption: 250W and 500W
  • Supports POE+ IEEE 802.3at/af and 24V Passive PoE
  • Rackmountable

UniFi Switch 48

UniFi Switch 48

  • (48) Gigabit RJ45 Ports
  • (2) SFP+ Ports
  • (2) SFP Ports
  • (1) Serial Console Port
  • Non-Blocking Throughput: 70 Gbps
  • Switching Capacity: 140 Gbps
  • Forwarding Rate: 104.16 Mpps
  • Maximum Power Consumption: 56W
  • Rack-Mountable

UniFi Switch 48 PoE

UniFi Switch 48 PoE

  • (48) Gigabit RJ45 ports
  • (2) SFP+ ports
  • (2) SFP ports
  • (1) Serial console port (reserved for future use)
  • Non-blocking throughput: 70 Gbps
  • Switching capacity: 140 Gbps
  • Forwarding rate: 104.16 Mpps
  • Maximum power consumption: 500W and 750W
  • Supports POE+ IEEE 802.3at/af and 24V Passive PoE
  • Rackmountable
